Applications:
Chemical fumes and gases suction in ventilation and air conditioning systems
Properties:
Good chemical resistance particularly to solvent and other aggressive fumes, halogene-free
Temperature Resistance:
– 40°C to + 60°C
Material:
Polyethylene, translucent
Single Length:
Available in 6m, 10m and 15m lengths
Special Constructions:
P 2 PE EL: Conductive (R<104 Ohm)
Colour: Black, compliant with TRBS 2153 and ATEX-guideline 94/9/EC
Stand:
October 23, 2019
Technical Data
| Dia. (mm) |
Weight (kg/m) |
Mat. Thickness (mm) |
Bend. Rad. (mm) |
Max. Work. Press. (bar) |
Max. Vacuum (bar) |
| 40 | 0.11 | 0.4 | 28 | 0.45 | 0.18 |
| 50 | 0.14 | 0.4 | 35 | 0.40 | 0.16 |
| 60 | 0.17 | 0.4 | 42 | 0.40 | 0.16 |
| 70 | 0.20 | 0.4 | 49 | 0.30 | 0.12 |
| 75 | 0.21 | 0.4 | 53 | 0.30 | 0.10 |
| 80 | 0.22 | 0.4 | 63 | 0.30 | 0.10 |
| 90 | 0.25 | 0.4 | 70 | 0.25 | 0.09 |
| 100 | 0.28 | 0.4 | 70 | 0.20 | 0.09 |
| 125 | 0.35 | 0.4 | 85 | 0.20 | 0.08 |
| 150 | 0.43 | 0.4 | 100 | 0.10 | 0.06 |
| 175 | 0.71 | 0.4 | 123 | 0.09 | 0.05 |
| 200 | 0.81 | 0.4 | 140 | 0.08 | 0.05 |
| 250 | 1.01 | 0.4 | 175 | 0.05 | 0.04 |
| 300 | 1.22 | 0.4 | 210 | 0.03 | 0.03 |
| 350 | 1.42 | 0.4 | 245 | 0.02 | 0.02 |
| 400 | 1.62 | 0.4 | 280 | 0.02 | 0.02 |
| 450 | 1.83 | 0.4 | 315 | 0.01 | 0.01 |
| 500 | 2.03 | 0.4 | 350 | 0.01 | 0.01 |
| 600 | 3.48 | 0.4 | 400 | 0.01 | 0.01 |
